INSIDE stage v1.1

Pipelines v1.9

Purpose, Operands, Streams used, Usage notes, Examples, See also

Home

Syntax


 _STRing__ _STRing__
>>__INSIDE__ ____________ __|_________|__fromstring__|_________|__ _tostring_ _________><
 |_CASEI(...)_| |_REGexp__| |_REGexp__| |_numrecs__|
 |_ZONE(...)__|  |_PATtern_| |_PATtern_|
 |_ANYof___| |_ANYof___|


Purpose

Use the INSIDE stage to select groups of records from its primary input stream, starting with the first record following the record that begins with fromstring. INSIDE writes a group of records to its primary output stream, ending a group just prior to the record that contains tostring or the record corresponding to the specified number; numrecs. Each specified target string must begin in the first column of an input record.

Unless the CASEI or ZONE pre-process option specifies a different column range, both fromstring and tostring must begin in the first column of an input record. If the secondary output stream is connected, INSIDE writes the records that are not selected to its secondary output stream. If the secondary output stream is not connected, INSIDE discards these records.

Operands

●

CASEI

perform a non-case-sensitive comparison between the strings and an input record.

●

ZONE

restrict data selection to a specific column, word or field range.

●

STRing

specifies that the string operand is a literal string of characters to locate. A null string matches a null record.

●

REGexp

specifies that the string operand is a regular expression of characters to locate.

●

PATtern

specifies that the string operand is a pattern of characters to locate.

●

ANYof

specifies that the string operand is a list of characters; any of which are to be located.

●

fromstring tostring are the starting string to locate fromstring and the ending string to locate tostring, respectively. If tostring is specified and it consists of only decimal numbers (0-9), you cannot specify a number as the delimiting character. You cannot use a B, b, H, h, X or x for a delimiting character.

●

numrecs

is an unsigned integer which specifies the number of records to be written to the primary output stream, starting with and including the record immediately following the record that begins with fromstring. INSIDE writes numrecs records each time fromstring is located. numrecs must be 0 or greater. If the number of records remaining in the input stream is less than numrecs, the remaining records are written to the primary output stream.

Streams used

The following streams are used by the INSIDE stage:

Stream	Action
Primary input stream	INSIDE reads records from its primary input stream.
Primary output stream	INSIDE writes to its primary output stream all selected records.
Secondary output stream	If its secondary output stream is connected, INSIDE writes all input records not selected to its secondary output stream.

Usage notes

1)	INSIDE does not delay the records.
2)	If the INSIDE stage discovers that all of its output streams are not connected, the INSIDE stage ends.
3)	If tostring is specified and it consists of only decimal numbers (0-9), you cannot specify a number as the delimiting character. For example, inside /a/ /7/ is not equivalent to inside 1a1 171 The first INSIDE stage selects records between records with the targets a and 7 . The second stage selects records that follow the record that begins with a for a total of 171 records. That is, 171 is processed as numrecs rather than as a delimited string.
4)	If the input stream does not contain a record that begins with tostring, INSIDE writes all the records in its input stream to its primary output stream, starting with the record immediately following the record that begins with fromstring. For example, after issuing the following pipe command: C:\>pipe ”< abc.txt | inside /ccc/ /rrr/ | console” the contents of the primary input stream (which is the data from the file abc.txt ), the primary output stream, and the secondary output stream are:
5)	If multiple sets of the strings are found, INSIDE will complete the first group before writing the second group. For example, if you specify the from and to strings and a second occurrence of fromstring is found before tostring, INSIDE writes the records that are between the first occurrence of fromstring and tostring to its primary output stream. These records do not include the records that begin with fromstring and tostring, but they do include the second record that begins with fromstring. For example, after issuing the following pipe command: C:\>pipe “< abc.txt | inside /aaa/ /ccc/ | console” the contents of the primary input stream (which is the data from the file abc.txt ), the primary output stream, and the secondary output stream are: Similarly, if you specify fromstring and numrecs and a second occurrence of fromstring is found within the selected group of records, INSIDE writes numrecs records starting with the record following the record that begins with fromstring and including the record that begins with the second occurrence of fromstring to its primary output stream. For example, after issuing the following pipe command: C:\>pipe “< abc.txt | inside /aaa/ 4 | console” the contents of the primary input stream (which is the data from the file abc.txt ), the primary output stream, and the secondary output stream are:
6)	If you specify the ZONE pre-process option of the INSIDE stage, each string must begin in the first column of the specified column range instead of the first column of the input record. To be selected, each string must be completely located within the column range; therefore, the length of the string must be less than or equal to the width of the column range.
7)	INSIDE verifies that its secondary input stream is not connected and then begins execution.

Examples

See: Usage notes, above.

See also

Reference the following links for additional information:

CASEI, FROMLABEL, OUTSIDE, TOLABEL, ZONE
